OPTIMUS™ Zero Turn Ride-On 152 cm 24 kwh R
OPTIMUS™ Zero Turn Ride-On 152 cm 24 kwh R

 Zero Turn Ride-On 152 cm 24 kwh R

The ZTC152R Zero Turn is powered by the MEGA 24K battery exclusive to Cramer’s OptimusZ range of product, the mower offers a cutting area of up to 85,000 m² on a single charge. This model offers a 152 cm cutting width with rear discharge and optional high-performance mulching.

  • Cut areas of up to 85,000 m² on a single charge
  • A combination of an equivalent power of 65 HP and a blade tip speed of up to 3400
  • rpm, superior cut quality is generated every time, every day.
  • 360 degree lighting keeps the operator safe in lower light conditions
  • No toxic emissions, no fumes, very low vibrations and little to no noise for the best
  • operator comfort and experience
  • 5 individually controlled electric motors deliver speed without sacrificing cut quality in all conditions.
Technical Spec DownloadsCompare Similar

Technical Spec

  • Voltage
    Optimus 82V
  • Max Area Coverage
    up to 85.000 m²
  • Max Runtime
    up to 8 hrs
  • Battery Capacity
    24 kWh
  • Translation missing: en.tech_spec.battery_compartments
    Built-In
  • Cutting Deck Width
    152 cm
  • Cutting Desk Type
    Fabricated
  • Cutting System
    Rear-discharge/Mulching
  • Translation missing: en.tech_spec.charge_time_with_3_kw_charger
    8 hrs
  • Equivalent
    65 HP
  • Drive Motors
    2x 5 kW, Hub Motors
  • Translation missing: en.tech_spec.cutting_motors
    3x 2 kW
  • Max Slope Capacity
    20°
  • Max Drive Speed
    up to 25.6 km/h
  • Max Blade Tip Speed
    up to 3,200 RPM
  • Cutting Height
    25 - 127 mm
  • Cutting Height Adjustment
    Manual (17 positions)
  • Height Adjustment
    Manual
  • Translation missing: en.tech_spec.max_carry_weight
    110 kg (rear)
  • ETO Connector Front Rear
    Front/Rear
  • Roll Over Protection
    Yes
  • Integrated Tow Hitch
    Yes
  • Translation missing: en.tech_spec.seat
    Suspension seat
  • Translation missing: en.tech_spec.parking_brake
    Electromagnetic
  • Operating Weight
    720 kg
  • ERP
    7401686
  • EAN
    6936854138252
View product View More Specifications
OPTIMUS™ Zero Turn Ride-On 152 cm 24 kwh R
Compare this product to others
Battery Capacity
Translation missing: en.tech_spec.battery_compartments
Charge Time
Translation missing: en.tech_spec.charge_time_with_3_kw_charger
Cutting Desk Type
Cutting Deck Width
Cutting Height
Cutting Height Adjustment
Cutting Height Span
Translation missing: en.tech_spec.cutting_motors
Cutting System
Drive Motors
EAN
Equivalent
ERP
ETO Connector Front Rear
Integrated Tow Hitch
Translation missing: en.tech_spec.led_360_warning_lights
Max Area Coverage
Max Blade Tip Speed
Translation missing: en.tech_spec.max_carry_weight
Max Drive Speed
Max Runtime
Max Slope Capacity
Operating Weight
Translation missing: en.tech_spec.parking_brake
Roll Over Protection
Translation missing: en.tech_spec.seat
Voltage
View more
OPTIMUS™ Zero Turn Ride-On 152 cm 24 kwh R
OPTIMUS™ Zero Turn Ride-On 152 cm 24 kwh R
Battery Capacity
24 kWh
Translation missing: en.tech_spec.battery_compartments
Built-In
Charge Time
8 hrs
Translation missing: en.tech_spec.charge_time_with_3_kw_charger
8 hrs
Cutting Desk Type
Fabricated
Cutting Deck Width
152 cm
Cutting Height
25 - 127 mm
Cutting Height Adjustment
Manual (17 positions)
Cutting Height Span
25 - 127 mm
Translation missing: en.tech_spec.cutting_motors
3x 2 kW
Cutting System
Rear-discharge/Mulching
Drive Motors
2x 5 kW, Hub Motors
EAN
6936854138252
Equivalent
65 HP
ERP
7401686
ETO Connector Front Rear
Front/Rear
Integrated Tow Hitch
Yes
Translation missing: en.tech_spec.led_360_warning_lights
360° LED Light / Warning Light
Max Area Coverage
up to 85.000 m²
Max Blade Tip Speed
up to 3,200 RPM
Translation missing: en.tech_spec.max_carry_weight
110 kg (rear)
Max Drive Speed
up to 25.6 km/h
Max Runtime
up to 8 hrs
Max Slope Capacity
20°
Operating Weight
720 kg
Translation missing: en.tech_spec.parking_brake
Electromagnetic
Roll Over Protection
Yes
Translation missing: en.tech_spec.seat
Suspension seat
Voltage
Optimus 82V
OPTIMUS™ Zero Turn Ride-On 182 cm 36 kWh R
OPTIMUS™ Zero Turn Ride-On 182 cm 36 kWh R
Battery Capacity
36 kWh
Translation missing: en.tech_spec.battery_compartments
Built-In
Charge Time
12 hrs
Translation missing: en.tech_spec.charge_time_with_3_kw_charger
12 hrs
Cutting Desk Type
Fabricated
Cutting Deck Width
182 cm
Cutting Height
25 - 127 mm
Cutting Height Adjustment
Electric (17 positions)
Cutting Height Span
25 - 127 mm
Translation missing: en.tech_spec.cutting_motors
3x 2 kW
Cutting System
Rear-discharge/Mulching
Drive Motors
2x 6.5 kW, Hub Motors
EAN
6936854138269
Equivalent
70 HP
ERP
7401786
ETO Connector Front Rear
Front/Rear
Integrated Tow Hitch
Yes
Translation missing: en.tech_spec.led_360_warning_lights
360° LED Light / Warning Light
Max Area Coverage
up to 100.000 m²
Max Blade Tip Speed
up to 3,200 RPM
Translation missing: en.tech_spec.max_carry_weight
110 kg (rear)
Max Drive Speed
up to 22.5 km/h
Max Runtime
up to 8 hrs
Max Slope Capacity
20°
Operating Weight
900 kg
Translation missing: en.tech_spec.parking_brake
Electromagnetic
Roll Over Protection
Yes
Translation missing: en.tech_spec.seat
Suspension seat
Voltage
Optimus 82V
FULL DETAILS
OPTIMUS™ Zero Turn Ride-On 132 cm 24 kwh
OPTIMUS™ Zero Turn Ride-On 132 cm 24 kwh
Battery Capacity
24 kWh
Translation missing: en.tech_spec.battery_compartments
Built-In
Charge Time
8 hrs
Translation missing: en.tech_spec.charge_time_with_3_kw_charger
8 hrs
Cutting Desk Type
Fabricated
Cutting Deck Width
132 cm
Cutting Height
25 - 127 mm
Cutting Height Adjustment
Manual (17 positions)
Cutting Height Span
25 - 127 mm
Translation missing: en.tech_spec.cutting_motors
3x 2 kW
Cutting System
Rear-discharge/Mulching
Drive Motors
2x 5 kW, Hub Motors
EAN
6936854138245
Equivalent
65 HP
ERP
7401586
ETO Connector Front Rear
Front/Rear
Integrated Tow Hitch
Yes
Translation missing: en.tech_spec.led_360_warning_lights
360° LED Light / Warning Light
Max Area Coverage
up to 75.000 m²
Max Blade Tip Speed
up to 3,400 RPM
Translation missing: en.tech_spec.max_carry_weight
110 kg (rear)
Max Drive Speed
up to 25.6 km/h
Max Runtime
up to 8 hrs
Max Slope Capacity
20°
Operating Weight
650 kg
Translation missing: en.tech_spec.parking_brake
Electromagnetic
Roll Over Protection
Yes
Translation missing: en.tech_spec.seat
Suspension seat
Voltage
Optimus 82V
FULL DETAILS
OPTIMUS™ Zero Turn Ride-On 152 cm 24 kwh
OPTIMUS™ Zero Turn Ride-On 152 cm 24 kwh
Battery Capacity
24 kWh
Translation missing: en.tech_spec.battery_compartments
Built-In
Charge Time
8 hrs
Translation missing: en.tech_spec.charge_time_with_3_kw_charger
8 hrs
Cutting Desk Type
Fabricated
Cutting Deck Width
152 cm
Cutting Height
25 - 127 mm
Cutting Height Adjustment
Manual (17 positions)
Cutting Height Span
25 - 127 mm
Translation missing: en.tech_spec.cutting_motors
3x 1.8 kW
Cutting System
Side-discharge/Mulching
Drive Motors
2x 5 kW, Hub Motors
EAN
6952909093475
Equivalent
65 HP
ERP
7401086
ETO Connector Front Rear
Front/Rear
Integrated Tow Hitch
Yes
Translation missing: en.tech_spec.led_360_warning_lights
360° LED Light / Warning Light
Max Area Coverage
up to 85.000 m²
Max Blade Tip Speed
up to 3,200 RPM
Translation missing: en.tech_spec.max_carry_weight
110 kg (rear)
Max Drive Speed
up to 25.6 km/h
Max Runtime
up to 8 hrs
Max Slope Capacity
20°
Operating Weight
720 kg
Translation missing: en.tech_spec.parking_brake
Electromagnetic
Roll Over Protection
Yes
Translation missing: en.tech_spec.seat
Suspension seat
Voltage
Optimus 82V
FULL DETAILS
OPTIMUS™ Zero Turn Ride-On 122 cm 24 kWh
OPTIMUS™ Zero Turn Ride-On 122 cm 24 kWh
Battery Capacity
24 kWh
Translation missing: en.tech_spec.battery_compartments
Built-In
Charge Time
8 hrs
Translation missing: en.tech_spec.charge_time_with_3_kw_charger
8 hrs
Cutting Desk Type
Fabricated
Cutting Deck Width
122 cm
Cutting Height
25 - 127 mm
Cutting Height Adjustment
Manual (17 positions)
Cutting Height Span
25 - 127 mm
Translation missing: en.tech_spec.cutting_motors
3x 2 kW
Cutting System
Rear-discharge/Mulching
Drive Motors
2x 5 kW, Hub Motors
EAN
6936854138238
Equivalent
65 HP
ERP
7401486
ETO Connector Front Rear
Front/Rear
Integrated Tow Hitch
Yes
Translation missing: en.tech_spec.led_360_warning_lights
360° LED Light / Warning Light
Max Area Coverage
up to 65.000 m²
Max Blade Tip Speed
up to 3,400 RPM
Translation missing: en.tech_spec.max_carry_weight
110 kg (rear)
Max Drive Speed
up to 25.6 km/h
Max Runtime
up to 8 hrs
Max Slope Capacity
20°
Operating Weight
600 kg
Translation missing: en.tech_spec.parking_brake
Electromagnetic
Roll Over Protection
Yes
Translation missing: en.tech_spec.seat
Suspension seat
Voltage
Optimus 82V
FULL DETAILS
OPTIMUS™ Zero Turn Stand-On 92 cm
OPTIMUS™ Zero Turn Stand-On 92 cm
Battery Capacity
8 kWh
Translation missing: en.tech_spec.battery_compartments
Built-In
Charge Time
3 hrs
Translation missing: en.tech_spec.charge_time_with_3_kw_charger
3 hrs
Cutting Desk Type
Fabricated
Cutting Deck Width
92 cm
Cutting Height
25 - 127 mm
Cutting Height Adjustment
Manual (17 positions)
Cutting Height Span
25 - 127 mm
Translation missing: en.tech_spec.cutting_motors
2x 1.8 kW
Cutting System
Side-discharge/Mulching
Drive Motors
2x 2.2 kW, Hub Motors
EAN
6952909093451
Equivalent
27 HP
ERP
7400886
ETO Connector Front Rear
Front
Integrated Tow Hitch
Yes
Translation missing: en.tech_spec.led_360_warning_lights
Front LED Light / Warning Light
Max Area Coverage
up to 28.000 m²
Max Blade Tip Speed
up to 3,600 RPM
Translation missing: en.tech_spec.max_carry_weight
110 kg (rear)
Max Drive Speed
up to 16 km/h
Max Runtime
up to 4.5 hrs
Max Slope Capacity
20°
Operating Weight
430 kg
Translation missing: en.tech_spec.parking_brake
Electromagnetic
Roll Over Protection
No
Translation missing: en.tech_spec.seat
Suspension seat
Voltage
Optimus 82V
FULL DETAILS
